Elcon 1000W DC-DC Converter

$547.00

This 1000W DC-DC Converter from Elcon provides 12V to power your vehicles accessories from the high voltage battery pack. It’s fully sealed (IP67), to allow mounting anywhere on your vehicle. Choose the input voltage that matches your high voltage battery pack.

SKU: N/A Category:

Description

-Supplies 12V/24V power to low-voltage applications in electric vehicles
-Output terminal can connect directly to 12V/24V backup battery pack
-Manages the charging process of backup battery automatically
-Fully Sealed Potting can be waterproof and dust-proof
-Temperature and Vibration Resistance

The 1000W IP67 Sealed DC-DC Converter can be connected in parallel, however, the output wires should be separate all the way to the battery or load, and be the same lengths. DO NOT join the ‘big’ output negative and positive together and then run a thick 2 AWG cable to the load. Instead, run two separate sets of smaller 6 AWG cables to the load, and the output currents should stay pretty close to equal.

See Technical Specs Doc for full specifications.

Weight 8 lbs
Dimensions 12 × 7 × 4 in
Input Voltage (DC)

72, 96/108, 144, 216, 320
